SE500LCW
Large Excavator
SE500LCW
Operating Weight(kg)
50500
Total power (kW)
562 / 1900
Bucket capacity (m³)
3.2
Parameter
| Parameter | SE500LCW |
|---|---|
| Operating weight (kg) | 50500 |
| Engine Power (rpm) | 1700 |
| Bucket capacity (m³) | 3.2 |
| External dimensions (mm) | 12175 × 3890 × 5495 |
| Bucket rod digging force (kN) | 285 |
| Bucket digging force (kN) | 340 |
| Rotating speed (r/min) | 8.3 |
| Travel speed (km/h) | 3.6 / 5.9 |
| Maximum digging height (mm) | 10890 |
| Maximum digging distance (mm) | 7620 |
| Maximum digging depth (mm) | 7420 |
| Emissions | Tier 3 / Stage II |
