SE60W
Small Excavator
SE60W
Operating Weight(kg)
5960
Total power (kW)
36.8 / 2200
Bucket capacity (m³)
0.22
Parameter
| Parameter | SE60W |
|---|---|
| Operating weight (kg) | 5960 |
| Engine Power (rpm) | 2050 |
| Bucket capacity (m³) | 0.22 |
| External dimensions (mm) | 5855 × 1880 × 2560 |
| Bucket rod digging force (kN) | 29 |
| Bucket digging force (kN) | 48 |
| Rotating speed (r/min) | 0–11 |
| Travel speed (km/h) | 2.7 / 4.6 |
| Maximum digging height (mm) | 5785 |
| Maximum digging distance (mm) | 3850 |
| Maximum digging depth (mm) | 3990 |
| Emissions | Tier 3 / Stage II |
